The Universal Media Server Kit is a professional high-performance Primary & Backup media server package built for demanding live production, projection, LED, immersive, and show-control environments.
This package includes two media servers, providing a Primary and Backup solution for professional productions where system redundancy and dependable performance are critical.
Each server is configured with Windows 10 Pro and powered by an AMD Ryzen Threadripper 3970X processor with 128GB of RAM. An NVIDIA Quadro RTX 6000 serves as the primary graphics processor for output feeds, while a dedicated NVIDIA T1000 is primarily used for GUI feeds.
NVIDIA Quadro Sync 2 provides professional synchronization capabilities for advanced multi-output and synchronized display applications.
Storage includes a 500GB Gen 4 M.2 operating system drive and a dedicated 2TB Gen 4 M.2 media drive, providing high-speed storage for operating system and media playback requirements.
Networking includes onboard 1G and 2.5G Ethernet plus a dedicated 10G Ethernet adapter for high-bandwidth production networks and media workflows.
Each server also features a Blackmagic DeckLink 8K Pro capture card for professional video I/O and an ASUS ROG Strix TRX40-XE motherboard. Power is provided by an 850W Platinum-rated power supply with an internally controlled high-airflow cooling configuration.
Onboard mini-jack audio is available, with an external audio interface available upon request.
This Primary & Backup package provides a powerful hardware platform for professional media-server applications and is well suited for live events, projection mapping, large-format LED, corporate productions, touring, immersive experiences, and other demanding video playback environments.

The Universal Media Server Kit is a high-performance professional media server platform configured for demanding video playback, processing, synchronization, and live production workflows.

Each server combines an AMD Ryzen Threadripper 3970X processor, 128GB RAM, NVIDIA Quadro RTX 6000 primary graphics, NVIDIA T1000 GUI graphics, NVIDIA Quadro Sync 2, Gen 4 M.2 storage, 10G networking, and Blackmagic DeckLink 8K Pro video I/O.

The system is offered as a two-server Primary & Backup package, providing a powerful hardware foundation for professional media-server and show-control applications.

• Complete Primary & Backup package – includes 2 media servers
• Configured for professional media-server and live production applications
• Windows 10 Pro operating system
• AMD Ryzen Threadripper 3970X processor
• 128GB RAM per server
• NVIDIA Quadro RTX 6000 primary GPU for output feeds
• NVIDIA T1000 dedicated GPU primarily for GUI feeds
• NVIDIA Quadro Sync 2 synchronization card
• 500GB Gen 4 M.2 operating system drive
• 2TB Gen 4 M.2 dedicated media drive
• 1G onboard Ethernet
• 2.5G onboard Ethernet
• Dedicated 10G Ethernet adapter
• Blackmagic DeckLink 8K Pro capture card
• ASUS ROG Strix TRX40-XE motherboard
• 850W Platinum-rated power supply
• Internally controlled high-airflow cooling configuration
• Onboard mini-jack audio
• External audio interface available upon request
• Designed for professional multi-output video workflows
• Ideal for projection, LED, live events, touring, immersive environments, and corporate productions
